Metal Spinning Machine X-400 Standard
The Metal Spinning Machine X-400 Standard is an advanced 4-axis machine designed for enhanced precision and versatility in metal spinning applications. Unlike the X-300 Simple, the X-400 features an additional axis, allowing for more complex shapes and finer control over the spinning process. This makes it ideal for producing intricate designs and high-quality finishes on a wider range of metal components. Its robust build and advanced control system ensure durability and consistent performance, catering to medium to large-scale production needs. Perfect for workshops and industrial settings, the X-400 Standard offers greater flexibility and efficiency, making it a superior choice for demanding metal spinning tasks.
In the table installation of double turret 2 double turret servo motor to control the rotation of work,that is A axis&Z axis.
Vorteile: flexible operation,more available tool positions
Disadvantages: small spinning pressure,suitable für thin material spinning.
It is generally recommended to do soft aluminum spinning more.
Produktparameter
Machines Modell | X-400 Standard | |
Max.Work-Piece Diameter | 420 mm | |
Work Piece Pallets Diameter | 420 mm | |
Shaft Height to Axis | 215±5 mm | |
Main Spindle Speed | 30-2700 r/min | |
Y Axis Stroke | 385 mm | |
X Axis Stroke | 400 mm | |
Distance from Spindle to Tail Shaft | 550 mm | |
Max.Tail-Stork Force | Air Pressure | 0.5Kn(Standard) |
Hydraulic | 1.5Kn(Optional) | |
Adjustable Range of Tail Stock | 150 mm | |
Tail-Stroke Travel | 300 mm | |
Eisen &Copper Processing Thickness | 0.4-1.0 mm | |
Aluminum Processing Thickness | 0.4-2.5 mm | |
Stainless Steel Processing Thickness | 0.5-0.8 mm | |
Stromversorgung | AC 380V (AC380V Three-Phase Four-Wire) | |
Positioning Accuracy | 0.02 mm | |
Quantity of Tools Position |
3 Axis 5 Tools(Standard)
| |
Machine Dimensions(L*W*H) | 2500*1450*1650 mm | |
Net Weight | 2160 KG | |
CNC System | KY-808xy | |
