Industrial ultrasonic cleaning line
Produktbeschreibung
Automatic ultrasonic cleaning and drying line is an automated equipment designed for batch processing of oil, residue and oxide layer on the surface of aluminum or stainless steel products, such as pots, plates, knives and forks, kettles, etc. This line is equipped with degreasing and dewaxing area, rinsing area, fan water cutting area and drying area, with a cleaning pass rate of 99% and a processing speed of 300-800 pieces/hour. The touch screen operation interface supports one-key adjustment of parameters.
Produkt Technische Daten
Cleaning process: ultrasonic cleaning, tap water rinsing, pure water rinsing * 2, fan water cut-off, oven drying
| Inner tank size | width 450mm, depth 500mm, plexiglass installed on the front of the machine; the whole machine is controlled by the road, equipped with 1 set of universal hangers |
| Konfiguration | equipped with 6 water cutting fans, 1 set of 0.5-ton pure water equipment, and 2 wind curtain machines |
| Machine main frame | 50mm*50mm square tube, material 201 stainless steel, inner tank plate 304 stainless steel, outer plate 201 stainless steel |
| Whole machine (approximately) | length 20000mm*width 1600mm*height 1600mm (specific dimensions are subject to actual production) |
| Power specifications | power supply: 3-phase 4-wire, AC380V, 50HZ |
| Total equipment power | 80kw, average energy consumption is about 35kw per hour |
| Control voltage | AC 220V |
| The whole machine circuit is controlled as a whole, and the main switch uses 250A, 4P air switch | |
Product Application
Industrial ultrasonic cleaning line is a top - tier solution for industries dealing with kitchen utensils, electroplated parts, and precision hardware
